调用相机拍照后截取指定尺寸大小

2016-01-14 14:53 阅读 8,582 次 评论 0 条

概要

启动Android手机相机功能拍照,拍照后将按照指定尺寸对图片进行裁剪,在当前界面显示裁剪后的效果,这个小功能经常使用在修改头像的应用中。

》修改头像应用案例
001-demo

系统相机

调用系统相机功能,拍摄照片,并将拍摄的照片保存在指定路径,完成后在当前界面显示,执行回调方法onActivityResult(int arg0,int arg1,Intent arg2),通过arg0参数判断是否拍照返回,arg2是返回的数据

  1. /**
  2.  * 调用系统相机
  3.  */
  4. private static File photoFile;
  5. private void goToTakePhoto() {
  6.     String tempFileName = System.currentTimeMillis() + ".jpg";
  7.     // 指定调用相机拍照后照片的储存路径
  8.     photoFile = new File(Environment.getExternalStorageDirectory(),
  9.             "temp_capture" + tempFileName);
  10.     Intent cameraintent = new Intent(MediaStore.ACTION_IMAGE_CAPTURE);
  11.     cameraintent.putExtra(MediaStore.EXTRA_OUTPUT, Uri.fromFile(photoFile));
  12.     startActivityForResult(cameraintent, RESULT_CAPTURE_IMAGE);
  13.
  14. }

系统截图

系统截图,需要设置截图的图片尺寸,图片保存的路径、名称,同样完成截图后,执行回调方法onActivityResult(int arg0,int arg1,Intent arg2),通过arg0参数判断是否截图返回,arg2是返回的数据

  1. /**
  2.      * 系统截图
  3.      *
  4.      * @param uri
  5.      */
  6.     private static File photoFinal;
  7.     public static void startPhotoZoom(Context context, Uri uri) {
  8.         Log.e("TeachCourse""------------裁剪");
  9.         photoUploadTempName = System.currentTimeMillis() + ".jpg";
  10.
  11.         File ZoomFile = new File(Environment.getExternalStorageDirectory()
  12.                 + "/temp");
  13.         if (!ZoomFile.exists()) {
  14.             ZoomFile.mkdirs();
  15.         }
  16.         photoFinal = new File(ZoomFile, photoUploadTempName);
  17.
  18.         Intent intent = new Intent("com.android.camera.action.CROP");
  19.         intent.setDataAndType(uri, "image/*");
  20.         intent.putExtra("crop""true");
  21.         intent.putExtra(MediaStore.EXTRA_OUTPUT, Uri.fromFile(photoFinal)); // 裁剪后临时储存的jpg,return为true,直接加入bundle,并finish
  22.         intent.putExtra("outputFormat", Bitmap.CompressFormat.JPEG.toString());
  23.         // aspectX,aspectY 是宽高的比例
  24.         intent.putExtra("aspectX"1);
  25.         intent.putExtra("aspectY"1);
  26.         // outputX,outputY 是裁剪图片宽高
  27.         intent.putExtra("outputX"700);
  28.         intent.putExtra("outputY"700);
  29.         intent.putExtra("scale"true);// 黑边
  30.         intent.putExtra("scaleUpIfNeeded"true);// 黑边
  31.
  32.         intent.putExtra("return-data"false);
  33.
  34.         intent.addCategory(Intent.CATEGORY_DEFAULT);
  35.
  36.         ((FragmentActivity) context).startActivityForResult(intent, PHOTO_CROP);
  37.
  38.     }

裁剪后效果

获取保存在手机SDCard中的图片,通过ImageView显示

  1. /**
  2.      * 获取裁剪后照片
  3.      *
  4.      * @param data
  5.      * @throws IOException
  6.      * @throws FileNotFoundException
  7.      */
  8.     private ImageView mCapture_img;
  9.     private void getImageFromSystem(Intent data) throws FileNotFoundException,
  10.             IOException {
  11.         if (data != null) {
  12.             File file = photoFinal;
  13.             if (file != null) {
  14.
  15.                 mCapture_img.setImageDrawable(Drawable.createFromPath(file
  16.                         .getPath()));
  17.                 Toast.makeText(MainActivity.this"裁剪成功", Toast.LENGTH_SHORT)
  18.                         .show();
  19.             }
  20.         }
  21.     }

设置图像形状

自定义CircleImageView继承ImageView,重写onDraw(Canvas canvas)方法,绘制圆形头像,代码如下:

  1. @Override
  2.     protected void onDraw(Canvas canvas) {
  3.         if (getDrawable() == null) {
  4.             return;
  5.         }
  6.
  7.         canvas.drawCircle(getWidth() / 2, getHeight() / 2, mDrawableRadius,
  8.                 mBitmapPaint);
  9.         if (mBorderWidth != 0) {
  10.             canvas.drawCircle(getWidth() / 2, getHeight() / 2, mBorderRadius,
  11.                     mBorderPaint);
  12.         }
  13.     }

》圆形头像裁剪
002-circle-imageview
